Marine Distribution Box >> Power Distribution Box >> Power Distribution Box
 |
 | |||||||||
 |
 | |||||||||
| Product Name | Power Distribution Box | |||||||||
| Product No. | MEPS002-PDB001 | |||||||||
|
General Specification | ||||||||||
| Standard | IEC 60439-1 | Classification Society | ABS/BV/DNV/NK/KR/RINA/LR/CCS | |||||||
| Ambient Temperature | 0~45 ¡æ | |||||||||
| Voltage | AC 380V/440V | |||||||||
| System | 3 Phase 3Wire | |||||||||
| Frequency | 50/60 Hz | |||||||||
| Busbar | Material | Copper | ||||||||
| Treatment | Tin-plated | |||||||||
|
Power Distribution Box | ||||||||||
| Panel | Material | Sheet Steel | Colour | External | Munsell 7.5BG 7/2 | |||||
| Installation Method | Wall-mounted | |||||||||
| Location | Indoor | |||||||||
| Degree of Protection | IP22 | Internal | Maker Standard | |||||||
| Service Accessibility | Front | |||||||||
| Colour Coding for Main Circuits | AC | Phase R or U or L1 | Green | DC |
Positive or P: Red Negative or N: Blue | |||||
| Phase S or V or L2 | Yellow | |||||||||
| Phase T or W or L3 | Brown | |||||||||
| Earth | Yellow/Green | |||||||||
| Breaker Type | MCCB (Fixed type) | |||||||||
|
Description | ||||||||||
| This kind of power distribution box is widely for marine power distribution system, with functions of overload protection, short circuit protection, the degree of protection can be IP22, IP23, IP44, IP56. | ||||||||||
