Marine Non-Metal Materials >> Panel System >> Ceiling >> Type A Ceiling PanelType A Aluminum Ceiling panel
| ¡¡ |
||||
| Product Name: | Type A Aluminum Ceiling panel | ||||
| Product No.: | MMDE300-CE004 | ||||
| Type | T25A | ||||
| Fire class | B-0 | ||||
| Dimension | 25mm(t)x550mm(w)xlength(max.3500mm) | ||||
| Weight | 10kg/m2 | ||||
| Sound reduction | dB | ||||
| Thermal transmittance | 3.35 Kcal/m2h£®¡æ | ||||
| Surface finish | PVC/PET film Laminated (low flame-spread) or galvanized Steel sheet | ||||
| Tolerances | Width¡À1 , Height ¡À3 , Thickness¡À1 | ||||
| Core material | Aliuminum honeycomb | ||||
