| Product Name: | Type D Ceiling panel | ||||
| Product No.: | MMDE300-CE006 | ||||
| Type | T25D | ||||
| Fire class | B-0 | ||||
| Dimension | 25mm(t)x300mm(w)xlength(max.3900mm) | ||||
| Weight | 7.9kg/m2 | ||||
| Sound reduction | 0.8dB | ||||
| Thermal transmittance | 1.36Kcal/m2h£®¡æ | ||||
| Surface finish | PVC/PET film Laminated (low flame-spread) or galvanized Steel sheet | ||||
| Tolerances | Width¡À1 , Height ¡À3 , Thickness¡À1 | ||||
| Core material | Rock wool 180kg/m3 | ||||
