| Product Name: | Type F Ceiling panel | ||||
| Product No.: | MMDE300-CE009 | MMDE300-CE010 | |||
| Type | T25F | T50F | |||
| Fire class | B-0 | B-15/B-30 | |||
| Dimension | 25/50mm(t)x600mm(w)x600mm(l) | ||||
| Weight | 1.36kg/m2 | 17.7kg/m2 | |||
| Sound reduction | dB | dB | |||
| Thermal transmittance | 1.13 Kcal/m2h£®¡æ | 0.89Kcal/m2h£®¡æ | |||
| Surface finish | PVC/PET film Laminated (low flame-spread) or galvanized Steel sheet | ||||
| Tolerances | Width¡À1 , Height ¡À3 , Thickness¡À1 | ||||
| Core material | Rock wool 180kg/m3 | ||||
