Marine Furniture >> Marine Vinyl >> Marine VInyl
|
|
| ||
| Product Name | Marine Vinyl | ||
| Product No. | MDMV100-002 | ||
| Item | Condition | Result | Standard |
| Composition | Surface | 100% PVC | |
| Backing Fabric | Single Side Knitting | ||
| Thickness(mm) | 1.2 | ||
| Width(In) | 54"~55" | ||
| Weight(g/m2) | 820 | ||
|
Ultraviolet Protection Factor(UPF) |
50+ | AATCC 183-2000 | |
| Tensile Strength(KG) | Weft x Warp | 15 | CNS,ASTM,BS |
| 100mm x 30mm | 25.3 | ||
| Tensile Elongation(%) | Weft x Warp | 140% | CNS,ASTM,BS |
| 100mm x 30mm | 57% | ||
| Tear Strength(KG) | Weft x Warp | 5.1 | ASTM-D2210 |
| 100mm x 30mm | 5 | ||
| Breaking Strength(KG/CM²) | Weft x Warp | 11.9 | BS-3144, JIS-K6545 |
| 50mm x 50mm | |||
| Force of adhesion of Surface to backing | Weft x Warp | 3.9 | CNS,ASTM,BS |
| 100mm x 30mm | 4.9 | ||
| Fire Retardancy | pass | BS5852 part 1 | |
