| Product Name | Adjustable Lifting Grab | ||||||
| Product Material | Steel | ||||||
| Product No. | WLL | Score of application | Max Thickness of Clamp | Span | Max Overall Size | Weight | |
| W | H | ||||||
| MHAE019-AL001 | 16 | 1450-1600 | 150-600 | 800 | 2600 | 5.6 | 5600 |
| MHAE019-AL002 | 25 | 1500-1600 | 230-690 | 950 | 2700 | 8.5 | 8500 |
| MHAE019-AL003 | 32 | 1050-2100 | 150-500 | 180 | 4100 | 13.5 | 13500 |
| MHAE019-AL004 | 50 | 1200-2300 | 200-600 | 1200 | 4200 | 17 | 17000 |
| Note: 1. That clamp dote lever principle with and open a shut automatism, its structure is simple and reasonable, operating cicely, lighting on the safe side. No need to provide any drive, depending on the self-respect lock, switches fixed position. 2. The clamp can also create folders based on taking into billets length of the block a few adjustments to the special clamp device to ensure that the steel was being lifted throughout the course of stability and security. | |||||||
