Product Name |
Hoist Eye Hooks | |||||||||||||||
|
Product Material |
CarbonAlloy | |||||||||||||||
| Product No. | Working Load Limit (t) | Dimensions (mm) | ||||||||||||||
|
Carbon |
Alloy |
C |
D |
F |
G |
J |
K |
M |
N |
O ? |
O2 |
Q |
T ? |
T2 |
AA | |
|
MHAE0152-HE001 |
3/4 |
1 |
85.0 |
72.0 |
31.8 |
18.5 |
22.9 |
16.0 |
16.0 |
9.14 |
22.6 |
- |
19.1 |
22.1 |
- |
38.1 |
|
MHAE0152-HE002 |
1 |
1-1/2 |
97.0 |
79.0 |
35.1 |
21.3 |
23.6 |
18.0 |
18.0 |
10.7 |
23.1 |
- |
23.1 |
24.9 |
- |
50.8 |
|
MHAE0152-HE003 |
1-1/2 |
2 |
105 |
89.5 |
38.1 |
25.4 |
25.4 |
22.4 |
22.4 |
14.0 |
25.4 |
- |
28.7 |
26.2 |
- |
50.8 |
|
MHAE0152-HE004 |
2 |
3 |
119 |
101 |
41.4 |
28.7 |
28.7 |
23.9 |
23.8 |
14.7 |
27.7 |
- |
31.8 |
29.5 |
- |
50.8 |
|
MHAE0152-HE005 |
3 |
5 |
147 |
122 |
51.0 |
36.6 |
37.3 |
33.3 |
33.3 |
18.3 |
34.5 |
25.4 |
39.6 |
38.9 |
38.1 |
63.5 |
|
MHAE0152-HE006 |
5 |
7 |
187 |
159 |
63.5 |
46.0 |
44.5 |
42.2 |
42.2 |
22.9 |
40.9 |
33.3 |
51.0 |
49.8 |
47.7 |
76.2 |
|
MHAE0152-HE007 |
7-1/2 |
11 |
230 |
189 |
76.0 |
57.0 |
58.0 |
47.8 |
41.4 |
28.2 |
53.0 |
46.0 |
62.0 |
62.5 |
57.2 |
102 |
|
MHAE0152-HE008 |
10 |
15 |
256 |
211 |
82.5 |
66.0 |
63.5 |
55.5 |
49.3 |
32.3 |
57.5 |
51.0 |
72.0 |
66.5 |
58.7 |
102 |
|
MHAE0152-HE009 |
15 |
22 |
318 |
262 |
108 |
76.0 |
84.0 |
68.5 |
60.5 |
39.6 |
76.5 |
69.8 |
89.0 |
72.0 |
65.0 |
127 |
|
MHAE0152-HE010 |
20 |
30 |
357 |
346 |
127 |
92.0 |
102 |
76.0 |
76.2 |
44.5 |
82.5 |
- |
89.0 |
87.5 |
- |
165 |
|
MHAE0152-HE011 |
25 |
37 |
462 |
357 |
137 |
116 |
108 |
102 |
81.0 |
51.0 |
76.0 |
- |
114 |
98.5 |
- |
178 |
|
MHAE0152-HE012 |
30 |
45 |
511 |
392 |
152 |
129 |
121 |
114 |
82.6 |
55.4 |
86.0 |
- |
125 |
121 |
- |
203 |
|
MHAE0152-HE013 |
40 |
60 |
602 |
470 |
178 |
152 |
146 |
140 |
99.3 |
64.3 |
105 |
- |
145 |
145 |
- |
254 |
