Product Name:Blender Equipment |
||||||||||
Product NO.:MOHS601BE-001 |
||||||||||
Advantages:The equipment is intended not only to homogenize fuel oil,but also: |
||||||||||
To cut and smash soft silt in blended oil more fully,thus make dripping much finer because of high-efficiency mixer. |
||||||||||
With high-fineness Micron Blender,to filtrate harmful particulates such as SO2 and Al2O3 etc |
||||||||||
To burn mixing oil more completely for engine ,thus save energy,greatly improve working condition in burning room fo engine and reduce maintenance expense of engine. |
||||||||||
Technical Parameters |
||||||||||
Type | Capacity | Speed | Working Pressure | Working Tem | Viscosity | Power | Voltage | Connecting Pipe | Motor Insolation Grade | Weight |
m3/h | r/min | Mpa | ℃ | Cst/50℃ | Kw/50Hz Hp/60Hz | V | mm | Kg | ||
MF30 | 3 | 2880/3490 | <1 | <160 | <700 | 3.0/4.0 | 380/440 | 34 | IP54 | 95 |
MF60 | 6 | 2900/3520 | <1.2 | 7.5/10 | 50 | 130 | ||||
MF90 | 9 | 2930/3540 | <1.2 | 11.0/15.0 | 50 | 180 | ||||
MF250 | 25 | 2940/3550 | <1.6 | 22/30 | 70 | 370 |
