Marine Window >> Side Scuttle >> Opening Side Scuttle >> Opening Welded Side ScuttleOpening Welded Side Scuttle (Light)
   | |||||||||||
|
Product Name |
Opening Welded Side Scuttle (Light) | ||||||||||
|
Available Certificate |
ABS, BV, NK, LR, DNV, CCS, GL, KR, RS, RINA, BIS etc. | ||||||||||
|
Description |
Meet IMO, SOLAS requirements | ||||||||||
|
Used for side and rear-end of superstructure above the freeboard deck | |||||||||||
|
Designed according to GB/T14413 and ISO1751 | |||||||||||
|
Watertight, gastight | |||||||||||
|
Material |
Steel, brass, aluminum | ||||||||||
|
Glass Option |
Clear glass, frosted glass, fireproof glass | ||||||||||
|
Specifications | |||||||||||
| Product No. | Nominal Size (D) | D1 | D3 | h | t (Y1) | a | gmax | Clip Quantity | Cutout Size | ||
| Deadlight | Frame | ||||||||||
| MOUE020-WC001 | 200 | 245 | 250 | 155 | 6 | 45กใ | 50 | \ | 3 | 253 | |
| MOUE020-WC002 | 250 | 295 | 305 | 182 | 6 | 42กใ | 47.5 | 308 | |||
| MOUE020-WC003 | 300 | 350 | 360 | 207 | 8 | 31กใ | 45 | 363 | |||
| MOUE020-WC004 | 350 | 400 | 410 | 232 | 8 | 32กใ | 45 | 413 | |||
| MOUE020-WC005 | 400 | 450 | 460 | 257 | 10 | 31กใ | 45 | 463 | |||
| MOUE020-WC006 | 450 | 500 | 510 | 282 | 10 | 31กใ | 45 | 4 | 513 | ||
