Product Name:Marine Disk Separator |
|||||||||
Product NO.:MOHS201COS-205 |
|||||||||
Structure: |
|||||||||
The product mainly consists of blow,vertical axis,horizontal axis,machinery frame,speed detector,braking device,controlling valve and electromotor. |
|||||||||
Feature: |
|||||||||
The product is ring valve full slagging type and can continuously run. |
|||||||||
Technical Parameters |
|||||||||
| Type | Rated Capacity | Rotate Speed | Discharge Type | Inlet Pressure | Output Pressure | Motor Power | Weight | Dimension | |
| L/h | r/min | Mpa | Mpa | Kw | Kg | L×B×H(mm) | |||
| AF-KYD207DD-23 | 3000 | 6300 | automatic | ≤0.05 | ≥0.2 | 5.5 | 705 | 1226×945×1380 | |
Condition For Mineral Oil Separation And Actual Capacity |
|||||||||
| Oil Type | Fuel oil | Lubrication Oil | |||||||
| Fuel oil | Heavy Fuel Oil | Marine L.O | Steam Turbine Oil | ||||||
| Kinematical Viscosity | 1.9-5.5 | 5.5-24 | 60 | 80 | 120 | 180 | 380 | 9.3-16.3 | 61.2-74.8 |
| 40℃ | 50℃ | 100℃ | 40℃ | ||||||
| mm2/s | |||||||||
| Density | <900 | 900-991 | 880-900 | <900 | |||||
| Kg/m3 20℃ | |||||||||
| Separate Temperature | 20 | 40 | 75 | 80 | 90 | 98 | 80-95 | 75 | |
| ℃ | |||||||||
| Recommended Capcity | 3900 | 3000 | 2100-2250 | 1800-1950 | 1650-1800 | 1350-1500 | 1050-1200 | 900-1800 | 2400-2550 |
| L/h | |||||||||
