Marine Split Type Air Conditioner,Marine Self-contained Air Conditioning,Marine Air Conditioning System -Product Details


Product Name	Marine Split Type Air Conditioner
Product NO.	MACS032-KS
Specifications
Model Item			KS075	KS095	KS122	KS150	KS182	KS200	KS221	KS246
Cooling Capacity		Btu/h	7,500	9,500	12,200	15,000	18,200	20,000	22,100	24,600
Heating Capacity		Btu/h	7,600	9,700	12,600	15,800	18,700	20,300	22,600	25,000
Power Supply			230V 50Hz
Cooling	Air Inlet Temp	℃	19/27
Cooling	Water Inlet Temp	℃	35
Heating	Air Inlet Temp	℃	16/22
Heating	Water Inlet Temp	℃	5
Refrigerant			R134A, R404A，R407C
Condenser Material			Cu/Ni
Indoor Unit	Length	mm	290	290	320	450	450	450	450	450
	Width	mm	270	270	270	320	320	320	320	320
	Height	mm	320	320	320	350	350	350	350	350
	Net Weight	kg	12	12	14	18	19	19	20	22
	Air Flow	m3/h	275	320	520	650	780	950	1,100	1,250
	Fan Motor Power	W	60	70	100	110	110	115	120	120
Outdoor Unit	Length	mm	330	330	330	330	330	330	330	330
	Width	mm	270	270	270	320	320	320	320	320
	Height	mm	320	320	340	370	370	370	400	400
	Net Weight	kg	17	18	19	25	27	27	29	32
Duct Diameter		mm	100	100	125	125	2x125	150	150	150
