Product Name |
Semi-watertight Hinged A60 Fire Door | ||||||||||
|
Description |
Meet IMO, SOLAS requirements | ||||||||||
|
Light and easy operation, passed standard fire test | |||||||||||
|
Powder-coat primer/RAL or NCS color, no painting for stainless steel doors | |||||||||||
|
Application |
Approved for use above freeboard deck | ||||||||||
|
Can be used on external positions where there's no need for heavy water tightness | |||||||||||
|
Water Pressure |
up to 3.5m either side of door | ||||||||||
|
Max. Size |
1000x2000mm | ||||||||||
|
Door Leaf |
2mm mild steel/galvanized steel/stainless steel | ||||||||||
|
Door Frame |
3mm mild steel/galvanized steel/stainless steel | ||||||||||
|
Hinges |
Galvanized/stainless steel | ||||||||||
|
Option |
Welded/bolted, Vision panel/kick-out panel | ||||||||||
|
Available Certificate |
GL, DNV, CCS, BV, ABS, LR, KR, RS, etc | ||||||||||
| Specifications | |||||||||||
| Product No. | Nominal Size | Frame Outer Limit | Cutout in Bulkhead | ||||||||
| B¡ÁL | B1¡ÁL1 | B2¡ÁL2 | |||||||||
| MOUE010-AQ001 | 600¡Á1600 | 692¡Á1692 | 702¡Á1702 | ||||||||
| MOUE010-AQ002 | 600¡Á1700 | 692¡Á1892 | 702¡Á1802 | ||||||||
| Sizes and colors will customize according to your requirements | |||||||||||
