Propeller Shaft System >> Tail Shaft Section >> Stern Tube Bearing >> White Metal BearingsStern Tube White Metal Bearings

Stern Tube White Metal Bearings

Product No. Type A B C N D1 D2 L L1 L2 L3 L4 L5 Weight(Kg)
mm mm mm mm mm mm mm mm mm mm mm F A
MPPE323-WMA001 WMA110 45 110 90 4 40 60 135 100 25 95 60 15 1.5 2
MPPE323-WMA002 WMA115 50 115 95 4 45 66 150 115 30 105 70 15 1.8 2.4
MPPE323-WMA003 WMA120 55 120 100 4 50 72 160 125 35 115 80 20 2.2 2.9
MPPE323-WMA004 WMA125 60 125 105 4 55 77 170 135 40 120 85 20 2.6 3.5
MPPE323-WMA005 WMA130 65 130 110 6 60 83 185 150 45 125 90 25 3.1 4.2
MPPE323-WMA006 WMA135 70 135 115 6 65 88 195 160 50 130 95 25 3.8 5.0
MPPE323-WMA007 WMA140 75 140 120 6 70 93 205 170 55 140 105 30 4.3 6.0
MPPE323-WMA008 WMA145 80 145 125 6 75 98 215 180 60 145 110 30 4.9 7.2
MPPE323-WMA009 WMA150 85 150 130 6 80 105 225 190 65 155 120 35 5.6 9.0
MPPE323-WMA010 WMA155 90 155 135 6 85 110 240 205 70 165 130 35 6.4 9.8
MPPE323-WMA011 WMA160 95 160 140 8 90 115 255 220 75 170 135 40 7.3 10.8
MPPE323-WMA012 WMA165 100 165 145 8 95 120 265 230 80 175 140 40 8.2 12
MPPE323-WMA013 WMA170 105 170 150 8 100 126 280 245 85 185 150 45 9.2 13.4
MPPE323-WMA014 WMA175 110 175 155 8 105 132 295 260 90 195 160 45 10.5 15
