Marine Valves >> ASME/ANSI/API Marine Valves >> Gate Valves >> Class 150 Bronze Gate ValveClass 150 Bronze Gate Valve
 |
 | ||||
| Product Name | Class 150 Bronze Gate Valve | ||||
| Product No. | DN | L | D | C | n-d |
| MFVEZB4-AN01 | 50 | 178 | 152 | 121 | 4-19 |
| MFVEZB4-AN02 | 65 | 191 | 178 | 140 | 4-19 |
| MFVEZB4-AN03 | 80 | 203 | 191 | 152 | 4-19 |
| MFVEZB4-AN04 | 100 | 229 | 229 | 191 | 8-19 |
| MFVEZB4-AN05 | 125 | 254 | 254 | 216 | 8-22 |
| MFVEZB4-AN06 | 150 | 267 | 279 | 241 | 8-22 |
| MFVEZB4-AN07 | 200 | 292 | 343 | 298 | 8-22 |
| MFVEZB4-AN08 | 250 | 330 | 406 | 362 | 12-25 |
| MFVEZB4-AN09 | 300 | 356 | 483 | 432 | 12-25 |
|
