Reduction Gearbox >> Heavy Duty >> Marine Reduction Gearbox
  |
||||||
| Marine Reduction Gearbox | ||||||
| Product No. | Inpt spd(RPM) | RATIO | Trans.Capacity/Rate (HP/RPM) |
Thrust(KN) | NetWeight (kg/lb) |
Reversal Step |
| MPPE213-HS07 MPPE213-HL07 |
400~800 400~1000 400~1200 400~1400 400~1600 400~1600 400~1600 400~1600 400~1600 |
1.9737 2.4671 2.8947 3.4660 3.9474 3.3741 4.8496 5.5024 5.9847 |
5.59 4.45 3.70 3.20 2.79 2.48 2.24 2.02 1.81 |
270 | 5280/11640 4600/10141 |
Yes No |
| Features | ||||||
| * Both are coaxial, and have double-step reduction, the same sense of rotation in input and output shaft. * Available for us to design solutions for the entire propulsion system, like gearbox, shafting, coupling, propeller, etc * All products available approved by ABS,BV,CCS,DNV,GL,LR,NK,etc., Certificated of Quality System ISO9001:2000 * Click to contact me for more technical details | ||||||
