Reduction Gearbox >> Heavy Duty >> Marine Reduction Gearbox
  |
||||||
| Marine Reduction Gearbox | ||||||
| Product No. | Inpt spd(RPM) | RATIO | Trans.Capacity/Rate (HP/RPM) |
Thrust(KN) | NetWeight (kg/lb) |
Reversal Step |
| MPPE213-HS06 MPPE213-HL06 |
400~800 400~1000 400~1200 400~1400 400~1600 400~1600 400~1600 400~1600 400~1600 |
2.0 2.5454 3.0244 3.5789 4.0 4.4706 5.0 5.60 5.9310 |
1.28 3.36 2.83 2.39 2.09 1.90 1.69 1.50 1.42 |
220 | 3980/8774 3470/7650 |
Yes No |
| Features | ||||||
| * Both are coaxial, and have double-step reduction, the same sense of rotation in input and output shaft. * Available for us to design solutions for the entire propulsion system, like gearbox, shafting, coupling, propeller, etc * All products available approved by ABS,BV,CCS,DNV,GL,LR,NK,etc., Certificated of Quality System ISO9001:2000 * Click to contact me for more technical details | ||||||
