Reduction Gearbox >> Heavy Duty >> Marine Reduction Gearbox
  |
||||||
| >Marine Reduction Gearbox | ||||||
| Product No. | Inpt spd(RPM) | RATIO | Trans.Capacity/Rate (HP/RPM) |
Thrust(KN) | NetWeight (kg/lb) |
Reversal Step |
| MPPE213-HS03 MPPE213-HL03 |
400~900 400~1150 400~1350 400~1600 400~1800 400~1800 400~1800 400~1800 400~1800 |
2.0585 2.5415 3.0211 3.5759 4.0526 4.5930 5.0894 5.5724 6.0789 |
1.83 1.48 1.25 1.05 0.93 0.82 0.73 0.67 0.61 |
113 | 2250/4960 2000/4409 |
Yes No |
| Features | ||||||
| * Both are coaxial, and have double-step reduction, the same sense of rotation in input and output shaft. * Available for us to design solutions for the entire propulsion system, like gearbox, shafting, coupling, propeller, etc * All products available approved by ABS,BV,CCS,DNV,GL,LR,NK,etc., Certificated of Quality System ISO9001:2000 * Click to contact me for more technical details | ||||||
