Reduction Gearbox >> Heavy Duty >> Marine Reduction Gearbox
  |
||||||
| Marine Reduction Gearbox | ||||||
| Product No. | Inpt spd(RPM) | RATIO | Trans.Capacity/Rate (HP/RPM) |
Thrust(KN) | NetWeight (kg/lb) |
Reversal Step |
| MPPE213-HS01 MPPE213-HL01 |
400~900 400~1150 400~1350 400~1600 400~1800 400~1800 400~1800 400~1800 400~1800 |
2.0607 2.5053 3.080 3.5353 4.0526 4.5351 5.0918 5.5861 6.1368 |
1.07 0.88 0.72 0.62 0.54 0.47 0.43 0.39 0.35 |
80 | 1230/2712 1070/2359 |
Yes No |
| Features | ||||||
| * Both are coaxial, and have double-step reduction, the same sense of rotation in input and output shaft. * Available for us to design solutions for the entire propulsion system, like gearbox, shafting, coupling, propeller, etc * All products available approved by ABS,BV,CCS,DNV,GL,LR,NK,etc., Certificated of Quality System ISO9001:2000 * Click to contact me for more technical details | ||||||
