Reduction Gearbox >> Heavy Duty >> Marine Reduction Gearbox
 |
 |
|||||
| Marine Reduction Gearbox | ||||||
| Product No. | Inpt spd(RPM) | RATIO | Trans.Capacity/Rate (HP/RPM) |
Thrust(KN) | NetWeight (kg/lb) |
Reversal Step |
| MPPE213-HS02 MPPE213-HL02 |
400~900 400~1150 400~1350 400~1600 400~1800 400~1800 400~1800 400~1800 400~1800 |
2.0317 2.5517 3.0370 3.5200 4.0 4.5455 5.0476 5.6410 6.054 |
1.45 1.15 0.97 0.84 0.73 0.64 0.58 0.51 0.47 |
100 | 1460/3219 1240/2734 |
Yes No |
| Features | ||||||
| * Both are coaxial, and have double-step reduction, the same sense of rotation in input and output shaft. * Available for us to design solutions for the entire propulsion system, like gearbox, shafting, coupling, propeller, etc * All products available approved by ABS,BV,CCS,DNV,GL,LR,NK,etc., Certificated of Quality System ISO9001:2000 * Click to contact me for more technical details | ||||||
