Container Securing Fitting >> Container Fixed Fitting >> Flush Container Foundation >> Flush Container foundation
 |
 | ||
|
Product Name |
Flush Container foundation(Quadruple Type) | ||
|
Material |
Casting steel or Ship building steel | ||
|
Min.Breaking Loads Tension |
500KN | ||
|
Shear |
420KN | ||
|
Min.Breaking Loads Compression |
2000KN | ||
|
Finish |
Weldable shop primer | ||
|
Certification |
All items are approved by major classification societies | ||
|
Product No. |
L(mm) | LC(mm) | |
|
MHAE221-FQ001-01 |
203 | 383 | |
|
MHAE221-FQ001-02 |
216 | 396 | |
|
MHAE221-FQ001-03 |
258 | 438 | |
|
Remark 1.Center marking for easy installation 2.We can produce them according to your request about the length,material and finish. | |||
