Product Name |
Single Raised Foundation (Welding Type) | |
|
Material |
Casting steel or ship building steel | |
|
Min.Breaking Loads Tension |
500KN | |
|
Min.Breaking Loads Shear |
420KN | |
|
Min.Breaking Loads Compression |
2000KN | |
|
Finish |
Weldable Shop Primer | |
|
Certification |
All items are approved by major classification societies. | |
|
Product No. |
H(mm) | Weight(kg) |
|
MHAE221-WS001-01 |
110 | 9.3 |
|
MHAE221-WS001-02 |
135 | 10.2 |
|
MHAE221-WS001-03 |
150 | 10.8 |
|
Remark | ||
