NINE ROLLER FAIRLEAD | |||||||||||
|
Specifications |
A |
B |
D |
E |
H |
L |
X¡ÁY | ||||
|
Product No. |
Type |
NominaPull |
Wire |
Rope |
Total |
Length |
¦µ |
Total |
Total |
Length |
Opening |
|
MOME102-NF001 |
FA-9-12 |
20KN |
-12mm |
22mm |
914mm |
626mm |
364mm |
82.5mm |
260mm |
490 |
180¡Á100 |
|
MOME102-NF002 |
FA-9-16 |
30KN |
-16mm |
28mm |
1130mm |
786mm |
454mm |
101.6mm |
330mm |
610 |
230¡Á120 |
|
MOME102-NF003 |
FA-9-20 |
50KN |
-20mm |
36mm |
1270mm |
900mm |
524mm |
127mm |
410mm |
715 |
250¡Á140 |
|
MOME102-NF004 |
FA-9-24 |
80KN |
-24mm |
48mm |
1420mm |
1000mm |
580mm |
139.7mm |
460mm |
800 |
280¡Á150 |
|
MOME102-NF005 |
FA-9-32 |
120KN |
-32mm |
60mm |
1680mm |
1150mm |
680mm |
177.8mm |
570mm |
915 |
300¡Á160 |
|
MOME102-NF006 |
FA-9-36 |
160KN |
-36mm |
72mm |
1820mm |
1250mm |
732mm |
194mm |
630mm |
1005 |
320¡Á170 |
|
MOME102-NF007 |
FA-9-40 |
200KN |
-40mm |
78mm |
1940mm |
1440mm |
856mm |
244.5mm |
780mm |
1145 |
340¡Á180 |
|
MOME102-NF008 |
FA-9-48 |
320KN |
-48mm |
96mm |
2400mm |
1720mm |
1026mm |
299mm |
960mm |
1355 |
400¡Á250 |
