Model

Unit

MDEE040-KT001

MDEE040-KT002

MDEE040-KT003

MDEE040-KT004

MDEE040-KT005

MDEE040-KT006

MDEE040-KT007

MDEE040-KT008

Lifting moment

[kNm]

38.77

58.15

77.7

83.8

126.5

137.4

173.4

214

Max. lifting moment

[kNm]

53.29

80.12

104.3

117.6

173.8

190.5

246.4

295

Max. Outreach

[m]

4.5

5.35

5.38

5.8

6.06

6.03

6.1

8

Slewing angle

[degree]

400

422

373

417

426

426

409

409

Max. rotation torque

[kNm]

15.98

16.24

16.14

16.4

25.37

25.37

51.7

44.43

Volume of oil tank

[l]

20

40

40

45

70

85

115

150

Max. working pressure

[bar]

195

220

210

230

230

230

210

250

Pump delivery

[l/min]

20

25

30

35

40

40

40

45

Max. power

[kW]/[CV]

7.64/10.39

10.78/14.6

12.35/17

15.7/21.4

18/24.5

18/24.5

16.5/22.4

23/31.2

Weight

[Kg]

730

915

1057

1115

1590

1810

2475

2850

Basic features:
Simple mounting by welding of the pedestal to deck and connecting the
power cable
No electric slipring
Fail-safe brakes on all movements
Welded box boom (jib) for low maintenance
Maintenance-free jib- and cylinder bearings.
Standard equipment:
Shot blasted to SA2,5 plus 2 layers of marine paint
Pedestal height between 1.1 and 1.5 m
Class certificate on the pedestal
Control platform on the Crane (left or right-hand side)
Full documentation/Owner's manua
Working radius and lifting capacity (SWL) according to customer's request
