| Product Name | SoleNoid Valve | |
| Product No. | ABRS810-RE011 | |
| Parameter | Operating Pressure(Bar) | 1 ... 11 |
| Type | Vented | |
| OperatingTemperature Range | -40¡æ~+100¡æ | |
| Port Thread | M 12x1.5 | |
| Port 4 | Bayonet DIN 72585-A1-2.1-Sn/K1 | |
| Duty Cycle | Continuous (100%) | |
| Protection Type(IP Code) | IP 66/69K | |
| Grade of insulation | ||
| Nominal Diameter | 2.2 /3 | |
| Voltage(V) | 24 | |
| Rated Current(A) | 0.41 | |
| Remark | - | |
| Wabco No. | OEM No. | Application |
| 472 172 626 0 | 1330025 | DAF |
| 41026587 | Iveco | |
| 5010347978 | Renault Trucks | |
| 1738496 | Scania | |
