| Product Name | SoleNoid Valve | |
| Product No. | ABRS810-RE010 | |
| Parameter | Operating Pressure(Bar) | 1 ... 11 |
| Type | Vented | |
| OperatingTemperature Range | -40¡æ~+100¡æ | |
| Port Thread | M 12x1.5 | |
| Port 4 | M 27x1 | |
| Duty Cycle | Continuous (100%) | |
| Protection Type(IP Code) | IP 6k6 /6K9 | |
| Grade of insulation | ||
| Nominal Diameter | 2.2 /3 | |
| Voltage(V) | 24 | |
| Rated Current(A) | 0.41 | |
| Remark | - | |
| Wabco No. | OEM No. | Application |
| 472 172 600 0 | 867177 | DAF |
| 1327108 | ||
| 0009970712 | Daimler | |
| A0009970712 | ||
| 658072 | Dennis | |
| 82855460000 | EVO-Bus | |
| 41016830 | Iveco | |
| 11017370 | Neoplan | |
| 5001843881 | Renault Trucks | |
| 5010376941 | ||
| 5021170194 | ||
