| Product Name | SoleNoid Valve | |
| Product No. | ABRS810-RE009 | |
| Parameter | Operating Pressure(Bar) | 5.5 ... 10.2 |
| Type | Vented | |
| OperatingTemperature Range | -40¡æ~+80¡æ | |
| Port Thread | M 12x1.5 | |
| Port 4 | M 27x1 | |
| Duty Cycle | Continuous (100%) | |
| Protection Type(IP Code) | IP 66 /69 | |
| Grade of insulation | ||
| Nominal Diameter | 4 | |
| Voltage(V) | 24 | |
| Rated Current(A) | 0.69 | |
| Remark | - | |
| Wabco No. | OEM No. | Application |
| 472 170 600 0 | 1505087 | DAF |
| 0049979036 | Daimler | |
| A0049979036 | ||
| 6570829 | Dennis | |
| 1170259 | ERF | |
| 97CT4K072AA | Ford | |
| 41016826 | Iveco | |
| 4460001013 | ||
| E4460001013 | ||
| 79100710104 | Man | |
| 11017377 | Neoplan | |
| 5010104266 | Renault Trucks | |
