| Product Name | SoleNoid Valve | |
| Product No. | ABRS810-RE007 | |
| Parameter | Operating Pressure(Bar) | 5.4 ... 11 |
| Type | Vented | |
| OperatingTemperature Range | -40¡æ~+70¡æ | |
| Port Thread | M 12x1.5 | |
| Port 4 | M 27x1 | |
| Duty Cycle | 30 % | |
| Protection Type(IP Code) | IP 66 A | |
| Grade of insulation | ||
| Nominal Diameter | 4 | |
| Voltage(V) | 24 | |
| Rated Current(A) | 0.65 | |
| Remark | Alternative: SoleNoid Not turnable | |
| Wabco No. | OEM No. | Application |
| 472 126 108 0 | 1505429 | DAF |
| AMPA978 | ||
| 49501111001 | Orthaus | |
| 5010104266 | Renault Trucks | |
| 526056006010 | Steyr | |
| 8037862 | Volvo | |
