| Product Name | SoleNoid Valve | |
| Product No. | ABRS810-RE006 | |
| Parameter | Operating Pressure(Bar) | Max. 8 |
| Type | Normally Open | |
| OperatingTemperature Range | -20¡æ~+70¡æ | |
| Port Thread | M 12x1.5 | |
| Port 4 | M 27x1 | |
| Duty Cycle | Continuous | |
| Protection Type(IP Code) | IP 65 | |
| Grade of insulation | ||
| Nominal Diameter | 4 | |
| Voltage(V) | 24 | |
| Rated Current(A) | 0.65 | |
| Remark | Alternative: SoleNoid Not turnable | |
| Wabco No. | OEM No. | Application |
| 472 125 708 0 | 0243105500 | BPW |
| 0039974436 | Daimler | |
| A0039974436 | ||
| 99708458396 | Faun | |
| 98417114 | Iveco | |
| 81991641802 | Man | |
| 11047718 | Neoplan | |
| 240612800 | ||
| 5010046405 | Renault Trucks | |
| 637209740 | Van Hool | |
