| Product Name | SoleNoid Valve | |
| Product No. | ABRS810-RE003 | |
| Parameter | Operating Pressure(Bar) | Max. 10 |
| Type | Vented | |
| OperatingTemperature Range | -40¡æ~+100¡æ | |
| Port Thread | M 12x1.5 | |
| Port 4 | M 27x1 | |
| Duty Cycle | Continuous | |
| Protection Type(IP Code) | IP 68 | |
| Grade of insulation | ||
| Nominal Diameter | 2.2 /3 | |
| Voltage(V) | 12 | |
| Rated Current(A) | 0.86 | |
| Remark | - | |
| Wabco No. | OEM No. | Application |
| 472 123 107 0 | 1504981 | DAF |
| 0014317506 | Daimler | |
| A0014317506 | ||
| 04850642 | Iveco | |
| 7700063843 | Renault Trucks | |
