Brake Control Mechanisms >> Pressure Limiting Valve >> Renault >> Pressure Limiting Valve For Renault
  | ||
| Product Name | Pressure Limiting Valve | |
| Product No. | ABRS809-RE006 | |
| Parameter | Max. Operating Pressure(Bar) | 20 |
| Delivered pressure(Bar) | 1.8¡À0.2 | |
| p1(Bar) | 8 | |
| Range of adjustment(Bar) | 1.5 ... 6.0 | |
| Port Thread | M 22x1.5 | |
| Nominal diameter | - | |
| Remark | With alternative the pipework will have to be changed | |
| Wabco No. | OEM No. | Application |
| 475 010 026 0 | 0243109600 | BPW |
| 1506189 | DAF | |
| 5100829001 | Foden Trucks | |
| 3299190R91 | Iveco | |
| 945333 | Krone | |
| 5010068962 | Renault Trucks | |
| 5430031008 | ||
| 4425007700 | Saf | |
| 3299190R91 | Seddon Atkinson | |
