| Product Name | Relay Emergency Valve | |
| Product No. | ABRS807-MA004 | |
| Parameter | Max.Operating Pressure(bar) | 10 |
| Operating Temperature Range | -40¡æ ~ +80¡æ | |
| Predominance(bar) | at 2 bar: 0.5 | |
| Port 1 | M 22x1.5 | |
| Port 2 | M 22x1.5 | |
| Port 1-2 | M 22x1.5 | |
| Port 4 | M 22x1.5 | |
| Port 41,42 | - | |
| Remark | Alternative: 971 002 150 0 or (971 002 300 0 is the same except without flange for manual LSV) | |
| Wabco No. | OEM No. | Application |
| 971 002 110 0 | 81523019148 | Man |
