| Product Name | Relay Valve | ||
| Product No. | ABRS801-RE005 | ||
| Parameter | Operating Pressure(bar) | 13 | |
| Operating Temperature Range | -40¡æ ~ +80¡æ | ||
| Port 1 | M 22x1.5 Voss | ||
| Port 2 | - | ||
| Port 3 | Silencer 432 407 050 0 | ||
| Port 4 | - | ||
| Port 21,22 | M 16x1.5 Voss | ||
| Port 41,42 | M 16x1.5 Voss | ||
| Wabco No. | OEM No. | Application | |
| 973 011 206 0 | 1518270 | DAF | |
| 5010260705 | Renault Trucks | ||
