| Product Name | Relay Valve | |
| Product No. | ABRS801-RE004 | |
| Parameter | Operating Pressure(bar) | 10 |
| Operating Temperature Range | -40¡æ ~ +80¡æ | |
| Port 1 | M 22x1.5 | |
| Port 2 | M 16x1.5 | |
| Port 3 | Schnap | |
| Port 4 | M 16x1.5 | |
| Port 21,22 | - | |
| Port 41,42 | - | |
| Wabco No. | OEM No. | Application |
| 973 006 000 0 | 1505412 | DAF |
| 8137884 | Iveco | |
| 81521166059 | Man | |
| 81521166062 | ||
| 81521166065 | ||
| 81521169065 | ||
| 7701012770 | Renault Trucks | |
